S/N
|
Description
|
Unit
|
Parameter value
|
|
1
|
Max. mixing diameter
|
mm
|
600
|
|
2
|
Max. mixing depth
|
m
|
12
|
|
3
|
Drilling rig dimension in transport condition (L × W × H)
|
mm
|
11490×2700×3250
|
|
4
|
Weight of overall unit (standard configuration, excluding drilling tool)
|
t
|
24
|
|
5
|
Engine
|
Model
|
|
Cummins QSF3.8
|
|
Rated power/speed
|
kW
|
84.3/2200r/min
|
|
6
|
Max. working pressure of hydraulic system
|
MPa
|
34.3
|
|
9
|
Rotary drive
|
Max. torque
|
KN.m
|
80
|
|
Rotational speed
|
r/min
|
6~30
|
|
10
|
Crowd winch
|
Max. Pushing force
|
KN
|
120
|
|
Max. Pulling force
|
KN
|
120
|
|
Max. Stroke
|
mm
|
9000
|
|
11
|
Main winch
|
Max. Pulling force
|
KN
|
90
|
|
Max. single-rope speed
|
m/min
|
75
|
|
Diameter of the steel wire rope
|
mm
|
20
|
|
12
|
Auxiliary winch
|
Max. pulling force
|
KN
|
35
|
|
Max. single-rope speed
|
m/min
|
60
|
|
Diameter of the steel wire rope
|
mm
|
14
|
|
13
|
Drilling mast
|
Left/right inclination of mast
|
°
|
±3
|
|
Front/back inclination of mast
|
°
|
4
|
|
14
|
Rotary table slewing angle
|
°
|
360
|
|
15
|
Traveling
|
Max. traveling speed of the overall unit
|
km/h
|
2.8
|
|
Max. climbable gradient of the overall unit
|
%
|
40%
|
|
External width of crawler
|
mm
|
2690
|
